Mounting Dream MD2465 - Wood Stud Installation

For wood stud installation, follow STEP 2A
For concrete installation, follow STEP 2B on PAGE 8
<16mm
(5/8")
Min. Wood Stud Size:
nominal 2"(51mm)
actual 1 1/2"(38mm)
Min. Wood Stud Size:
nominal 4"(102mm)
actual 3 1/2"(89mm)
Parts and Hardware
Wood Stud Installation
6
Wall Plate
Contact us at telephone (626) 604-9048 (USA)
Mon - Fri 10am - 6pm (Pacific time) or email us by
customerservice@mountingdream.com to have
these additional pieces shipped directly to you.
Concrete Wall Anchor
3pcs
Lag Bolt M6x50mm
x3
Mounting Template
