Bath Lift
Lifting capacity (person) 127kg/20 stone/280lbs
Net weight (excluding battery) 6.5kg/14.33lbs
Seat height UP 460mm/18.11in
Seat height DOWN (loaded) 70mm/2.76in
Power input 14.4V dc nominal 7A max
Duty cycle Not more than one bath per 15 minutes
Degree of protection IP66
Hand Control (Battery)
Input 14.4V dc nominal 1.0A
Output 14.4V dc nominal 7A max
Degree of protection IP68
Battery IP67
Battery Charger
Input 100-240V ac 50-60Hz 1.0A
Output 14.4V dc nominal 1.0A
Operating and charging
Temperatures
Max 40°C (104°F)
Min 0°C (32°F)
Shipping and storage
Weight (packaged) 9kg/19.84lbs
Shipping volume 0.12m
3
/4.24ft
3
Temperatures
Max 40°C (104°F)
Min -10°C (14°F)
Humidity
Max 90% RH
Min 10% RH
Pressure
Max 125kPa (18.4psi)
Min 73kPa (10.7psi)
14
This product is suitable for transport in
pressurised aircraft holds.
