MCTC manual
4.6.3 Unit events
Unit events can be set separately for each unit in a group.
Code
Event
Description
Default
3001
Minimum motor speed! (<0.1 RPM)
Required motor speed is too low
Warning
3002
Max RPM Exceeded
Required motor speed is too high
Warning
3003
CAN bus connection failure
CAN bus communication error
Warning
3004
Motor connection failure!
Short circuit detected!
Motor or cabling short circuit detected
Warning
3005
Motor connection failure!
Open connection detected!
Motor defect or not connected
Warning
3007
Load cell connection failure!
Load cell not connected or defective
Alarm
3008
Door open!
MCHybrid door open during production
Softalarm
3009
Weigh bin not empty
MCHybrid weigh bin not empty at production start
Softalarm
3010
Weigh bin missing
MCHybrid weigh bin not placed, or placed wrong
Alarm
3011
Actual batch weight exceeds
maximum batch weight!
More material is dosed in the weigh bin than allowed
Warning
3012
Emergency button pressed!
MCHybrid emergency button activated (Future use)
Alarm
3013
Pause time exceeded!
MCHybrid paused for more 10 minutes
Alarm
3014
Low mixer
MCHybrid200 mixer empty
Warning
3015
Pellets not loaded
Pellets are not sucked to disk
Alarm
3016
Not calibrated
MCNexus disk is not calibrated
Alarm*
4.6.4 Component events
Component events can be set separately for each component in a unit.
Code
Event
Description
Default
4001
Empty level!
Hopper level below empty level
Warning
4002
Low level!
Hopper level below low level
Warning
4003
High high level!
Hopper level above High High level (no RPM
regulation)
Warning
4004
Maximum deviation exceeded!
Deviation between set and act detected based on a
rough weight measurements
Warning
4005
Maximum deviation exceeded!
Deviation between set and act consistently bigger
than deviation alarm setting [default: 25%] based
Warning
4006
Maximum deviation exceeded!
MCHybrid deviation between set and act detected
Warning
4007
Suggested correction to high!
Suggested RPM correction too big, wrong dosing tool,
material rat-holing or hopper empty
Off
4008
Total correction to high
RPM correction too big, wrong dosing tool!
Off
4009
Filling system unable to load
material!
Fill system cannot complete filling within the set time
period
Warning
4010
Slide not closed!
Optional slide not closed
Warning
4011
Calculated dosing weight too small,
component skipped!
MCHybrid component dosing too small, component
skipped for this batch
Warning
4012
Material flow error! Hopper
empty?
MCHybrid component hopper material flow detected,
hopper (almost) empty?
Warning
4013
Minimum valve capacity reached!
Check valve configuration.
MCHybrid component skipped continuously, wrong
dosing valve mounted?
Warning
4014
Hopper Missing
Hopper is removed from unit
Alarm
4015
Pellets Deviated
MCNexus deviation between set and act detected.
Off
4016
Pellets Missing
MCNexus is missing pellets during dosing cycle.
Warning
4017
Filling limiting measurement time!
Time between filling cycles too short, system cannot
measure accurately.
Warning
* This event cannot be configured.
