Movacolor MCTC - Batch Mode Production Screen

43
MCTC manual
Batch mode production screen
Figure 3 Batch mode production screen
1.
Total batch weight
2.
Time unloading output is activated (only available when unloading option is enabled)
3.
Set point unit 1, percentage of the total batch weight
4.
Set point unit 2, percentage of the total batch weight
5.
Toggle button. With this button you can toggle between the normal and the detailed view.
1
3
2
4
5
