9 Outputs
MCBalance, MCPowder, MCHigh Output, MCLiquid
For the location of the output connections, see Electrical connections
Alarm / Warning Output
Connection 27 and 28.
Warning event: this output is on (24V), the system continues running).
Alarm event: this output is on (24V), the system stops running.
Free programmable events can be programmed to an Alarm or Warning. See chapter: Events. For alarm light
connection in multicomponent systems see paragraph: Alarm/warning output in the Multicomponent sector.
Valve Output
Connection 29 and 30. This output is on (24V) to start the hopper loader or open the knife gate.
Alarm Output (OUT-1)
Normally open contact, connection 32 and 33.
Normally closed contact, connection 32 and 34.
Alarm event: this output is activated, the systems stops running.
Run Output (OUT-2)
Normally open contact, connection 35 and 36.
The “RUN signal” can be used as a Start/Stop condition for the molding machine.
For example: Molding machine can only start in case dosing unit is also started.
Default the Run output 2 (OUT-2) is always on in production mode (status Dosing or Standby)
Production status = STANDBY or DOSING → output 35 and 36 is CLOSED.
Production status = OFF → output 35 and 36 is OPEN.
In case of alarm, the alarm output (OUT-1) is switched and the system is stopped. This also switches output OUT-2.
AUX Output (OUT-3)
Normally open contact, connection 41 and 42.
Function of OUT-3 depends on loader configuration.
