7. REVERSAL HEIGHT SETTING
a) Press and hold SET Button until “
1” appears on the display,
next press the UP button until “
l
” appears on the display to
enter this function setting then release the button.
b) Press the SET button again. The unit is now in reversal
height adjustment mode. And then you will see a gure “
0”
with ash dot appears on the display.
c) Press UP / DOWN button once to set the reversal height
while closing (0~9).
d) Press UP button to increase , or DOWN button to decrease.
Figure “
0” means the door will rebound to the open limit
position. Figure “1~9” means the door will rebound to the
position of the whole travel. One tenth to Nine tenth of the
whole travel etc...
e) Press SET button to conrm the set and it will back to
standby status automatically and display “ll”.
NOTE: The reversal height is set on “
0” as standard in factory.
-14D-
increase height
decrease height
