MODEL NAME CLIMATE PRO K36
Electronic Features Control Programmable
Cooling Capacity
Rating Conditions: 95°F, 60% RH
36,000 Btu/h
Electrical
Characteristics
Voltage Requirement 208/230V, 1Phase, 60Hz
Total Power Consumption 4.3 kW
Current Consumption 19.6 amps
Recommended Fuse Size 30 amps
NEMA Plug Confi guration 6-30
Min. - Max. Voltage 198 -253
Fans: Motor Output
Evaporator 0.23 kW
Condenser 0.38 kW
Evaporator
Fan Type Centrifugal
Max. Air Flow (hi/mid/low) 920/880/840 CFM
Max. External Static Pressure 0.6 IWG
Condenser
Fan Type Centrifugal
Max. Air Flow (hi/low) 1390/990 CFM
Max. External Static Pressure 0.5 IWG
Compressor
Type Hermetic Rotary
Output 2.3 kW
Refrigerant Type R-410A
Dimensions W x D x H 31 x 55 x 53 in
Weight Net / Shipping 470/535 lb
Power Cord
Gauge 12 AWG (3-core)
Length 6
Condensate Tank Capacity 2@5 gal
Operating Conditions
Min. 65°F (@ 50% RH)
Max. 95°F (@ 50% RH)
Max. Duct Length
Per Cold Duct Hose 40
Hot Duct Hose 60
Max. Sound Level
With Duct (hi/mid/low) 68/67/66 dB(A)
Without Duct (hi/mid/low) 70/69/68 dB(A)
74
TECHNICAL SPECIFICATIONS
Specifi cations are subject to change without notice.
