“Turbo Ring V2” DIP Switch Settings
DIP 1 DIP 2 DIP 3 DIP 4
ON: Enables the
default “Ring
Coupling
(backup)” port.
ON
: Enables this
EDS as the Ring
Master.
ON
: Enables the
default “Ring
Coupling” port.
ON
: Activates
DIP switches 1,
2, 3 to configure
“Turbo Ring V2”
settings.
OFF: Enables the
default “Ring
Coupling
(primary)” port.
OFF
: This EDS
will not be the
Ring Master.
OFF
: Do not use
this EDS as a
ring coupler.
OFF
: DIP
switches 1, 2, 3
will be disabled.
NOTE
If you do not enable any of the EDS-408A switches to be the Ring
Master, the Turbo Ring protocol will automatically choose the
EDS-408A with the smallest MAC address range to be the Ring
Master. If you accidentally enable more than one EDS-408A to be
the Ring Master, these EDS-408A switches will auto-negotiate to
determine which one will be the Ring Master.
NOTE
To switch on the Master or Coupler functions of the DIP switch,
you have to enable the Turbo Ring Pole first.
LED Indicators
There are several LEDs on the EDS’s front panel. The function of each LED is
described in the following table.
LED Color State Description
On
Power is being supplied to power
input PWR1
PWR1 AMBER
Off
Power is not being supplied to power
input PWR1
On
Power is being supplied to power
input PWR2
PWR2 AMBER
Off
Power is not being supplied to power
input PWR2
On
When (1) a relay warning event is
triggered, (2) the EDS-408A is the
Master of this Turbo Ring, and the
Turbo Ring is broken, or (3) start-up
failure
FAULT RED
Off
When a relay warning event is not
triggered
On
When this EDS-408A is the Master of
this Turbo Ring
MASTER GREEN
Blinking
When this EDS-408A is Ring Master
of this Turbo Ring and the Turbo Ring
has failed
To Next Page
