Panel Layout of EDS-408A-3M
(SC & ST-type)
EDS-408A-3M-SC
Front Panel View
Front Panel View
6
7
8
6
7
8
13
14
16
16
2
2
12
9
9
10
10
15
15
EDS-408A-3M-ST
13
14
11
11
12
RS-232 CONSOLE
------
MASTER
COUPLER
TURBO
RING
ONOFF
Top Panel View
1
2
3
5
4
1
Rear Panel View
2
18
17
17
43
2
1
NOTE: The appearance of
EDS-408A-3S-SC,
EDS-408A-1M2S-SC and
EDS-408A-2M1S-SC are identical to
that of EDS-408A-3M-SC.
1. Grounding screw
2. Terminal block for power input
PWR1/PWR2 and relay output
3. Console port
4. DIP switches
5. Heat dissipation orifices
6. Power input PWR1 LED
7. Power input PWR2 LED
8. Fault LED
9. Master LED
10. Coupler LED
11. 10/100BaseT(X) ports
12. TP port’s 100 Mbps LED
13. TP port’s 10 Mbps LED
14. 100BaseFX ports
15. 1 FX port’s 100Mbps LEDs
100M-M: multi mode FX port
100M-S: single mode FX port
16. Model Name
17. Screw hole for wall mounting kit
18. DIN-Rail kit
To Next Page
