Moxa Technologies UPort 1150 User Manual

UPort 1100 Series Installation and Configuration
2-5
Windows XP, Windows 2003/Vista, and Windows 2008 and
2012 (32-bit and 64-bit)
Case 1: The UPort Driver is Certified
If the UPort driver that you installed has been certified by Microsoft, the UPort and the UPort’s serial ports will
be installed automatically when you plug the UPort into your computer’s USB port.
Case 2: The UPort Driver is NOT Certified
If the UPort driver that you installed has not been certified by Microsoft, then plugging the driver into your
computer’s USB port will activate the UPort installation program. The first part of the installation procedure
installs the software for the UPort itself (the second part of the procedure installs the serial ports).
The following instructions are for Windows XP, Windows 2003/Vista, Windows 2008, and Windows 2012
systems.
1. After plugging the converter into a USB port, Windows will automatically detect the new device. The Found
New Hardware balloon will appear in the bottom right corner of the Windows desktop. No action is
required yet.
2. After a moment, the Found New Hardware Wizard will open. If you see the following screen, select No, not
this time, then click Next.

Moxa Technologies UPort 1150 Specifications

General

Connector 1	USB
Connector 2	DB-9M
Connector 1 gender	Male
Depth (imperial)	2.36 \
Width (imperial)	1.51 \
Height (imperial)	0.79 \
Weight (imperial)	0.14 lbs
Dimensions (WxDxH)	38.4 x 60 x 20 mm
Product color	Silver
Data transfer rate	0.012 Gbit/s
Compatible operating systems	Windows 98, ME, 2000, XP (x86/x64), 2003 (x86/x64), Vista (x86/x64) WinCE 5.0 Linux 2.6 (x86/x64), Linux 2.4 (x86/x64)
Input voltage	5 V

Weight and Dimensions

Weight	65 g
