MPPT MS2420N - Page 7

Code
E00
E02
E06
E07
E10
E13
E14
Error
No Error
Battery Over-voltage
Equipment
Overheating
Environment
Over-temperature
Solar Over-voltage
Solar Reverse
Polarity
Description
-
Battery voltage has
exceeded controller limit.
Controller exceeds
operating temperature
limit.
The device working
surrounding temperature
is too high, and the
controller would stop
charging anytime.
Solar array voltage
exceeds controller rated
input voltage.
Solar array input wires
connected with reverse
polarity.
Battery connection wires
connected with reverse
polarity.
Quick Troubleshoot
Check battery bank voltage for
compatibility with controller.
Ensure the controller is placed
in a well-ventilated cool, dry
place.
Try to lower the working
surrounding temperature.
Decrease the voltage of solar
panels connected to the
controller.
Disconnect and re-connect with
correct wire polarity.
Disconnect and re-connect with
correct wire polarity
Battery Reverse
Polarity
-
* Note: the missing error codes in the above chart indicates that this controller has no such
error or alarm condition.
12. Error Code Chart 13. Controller Specification
For example, the equalize charge voltage for a 12V FLD (Flooded) battery bank is 14.8V*1=14.8V.
The equalizing charge voltage for a 24V FLD (Flooded) battery bank is 14.8V*2=29.6V.
The variable “n” is adopted as a multiplying factor when calculating parameter voltages, the rule
for “n” is listed as: if battery system voltage is 12V, n=1; 24V, n=2; 36V, n=3; 48V, n=4.
300W/12V
600W/24V
450W/12V
900W/24V
600W/12V
1200W/24V
300W/12V
600W/24V
900W/36V
1200W/48V
450W/12V
900W/24V
1350W/36V
1800W/48V
600W/12V
1200W/24V
1800W/36V
2400W/48V
Max Solar Input
Power
FLD
14 8V n. *
14 6V n. *
SEL
14 6V n. *
14 4V n. *
GEL
( )default
–
14 2V n. *
USER
( )adjustable
Default
Default GEL:
LI
( )adjustable
–
Default 14 2V n: . *
13 8V n. *
13 2V n. *
- / /3mV 2V ºC
Default GEL:
Default GEL:
Default GEL:
–
–
–
–
Accessory List Package Status
Yes
Optional
Yes/Inbuit
Yes
Yes
Battery Voltages
Battery Types
Equalize Charge
Voltage
Boost Charge Voltage
Float Charge Voltage
Boost Charge
Recovery Voltage
Over-discharge
Recovery Voltage
Over-discharge
Voltage
Auto Temperature
Compensation
Battery Parameters
External Temperature
Sensor
Remote LCD Meter
Bluetooth Module
Parallel Charge Use
Cable
Installation Guidance
Paper
User Manual
Optional
-35ºC ~ +45ºC
IP34
1.0 kg 2.0 kg
12mA/12V ; 10mA/24V
<100Voc
20A 30A
≤ 3000 meters
190*120*59mm
40A
218*150*65mm
12V/24V
Auto (FLD/GEL/SLD)
MS2420 N MS2430 N MS2440 N MS4820 N MS4830 N MS4840N
12mA/12V;10mA/24V;8mA/36V;6mA/48V
12/24/36/48V
Auto (FLD/GEL/SLD)
Manual
(Li/User)
Manual
(Li/User)
<150Voc
20A 30A 40A
2.0 kg 1.1 kg 2.1 kg 2.1 kg
190*120*59mm 218*150*65mm
No-load Loss
Max Solar Input
Voltage
Rated Solar Charge
Current
Operating
Temperature
IP Protection
Net Weight
Communication Port
Operating Altitude
Controller Dimension
Controller Parameter
Model No.
Battery System
Voltage
Value
–
–
–
–
–
System Wiring
Grounded
Negative Grounded
RS485+Bluetooth(APP)
