mPTech myPhone MS2302 - Appearance of the Phone

EN © 2023 mPTech. All rights reserved. MS2302/MS2302e
25
Connectivity: Wi-Fi 802.11 a/b/g/n/ac, GPS, Bluetooth 5.0, NFC
2G: 850/900/1800/1900
3G: 900/2100
4G: 800/850/900/1800/2100/2300/2600
Battery:
MS2302 – Li-Poli 5000 mAh
MS2302e - Li-lon 5000 mAh
Additional functions: Fingerprint reader
Weight netto: 189g
Dimensions: 164.5 x 76 x 9.1mm
It is recommended to use the charger: myPhone SWIFTCHARGE DUO
Charger input parameters: AC 100-240V, 50/60Hz 1A
Charger output parameters:
USB-C: 3.3-11V/2.0A, 5V/3.0A,9V/2.22A, 12V/1.67A (20W MAX)
USB-A: 5V/3.0A,9V/2.0A, 12V/1.5A (18W MAX)
USB-C+USB-A: 5V/3.0A (15W MAX)
7. Appearance of the phone
Function
1
8 Mpx digital camera lens (selfie)
2
Camera flash / Torch
3
50 Mpx digital camera lens (rear)
4
The tray for SIM cards/ microSD
5
Volume control buttons
6
Blockade on/off button
7
External speaker
8
Multifunctional USB-C port
9
Minijack socket 3.5 mm
10
Microphone
11
Touchscreen 6.517”
