Mrcartool B530 - Copyright Information; Structure Description

To Next Page

To Previous Page

[1] Probe Tip [2] Red / Green Polarity Indicator [3] LCD Display

[6] Power Switch

[7] Mode Button [8] Speaker

[4] Clamps [5] Auxiliary Ground Lead

To avoid personal injury or damage to the vehicle or testing equipment, please

read the instructions and observe the following safety precautions before

working on the vehicle.

Always perform automotive testing in a safe environment.

Wear safety eye protection that meets ANSI standards.

Keep clothing, hair, hands, tools, test equipment, etc. away from all moving or

hot engine parts.

Operate the vehicle in a well-ventilated work area. Exhaust gases are

poisonous.

Put blocks in front of the drive wheels and never leave the vehicle unattended

while running tests.

Use extreme caution when working around the ingniton coil, distributor cap,

ignition wires and spark plugs. These components create hazardous voltages

when the engine is running.

Put the transmission in P(for A/T) or N(M/T) and make sure the parking brake is

engaged.

Don't connect or disconnect any test equipment while the ignition is ON or the

engine is running.

Keep the tool dry, clean free from oil/ water or grease. Use a mild detergent on

a clean cloth to clean the outside of the scan tool when necessary.

No part of this publication may be reproduced, stored in a retrieval system, or

transmitted in any form by any means, recording, mechanical, electronic, photo-

copying or otherwise, without the prior written permission of MRCARTOOL. The

information contained herein is designed only for the use of this unit.

MRCARTOOL is not responsible for any use of this information as applied to

other units.

Precautions

Structure Description
