MrCool Advantage Series User Manual

Page 5
Safety Precautions
mrcool.com
Remote Control
Remote Holder
Refrigerant Piping
Signal Cable
Drainage Pipe
Front Panel
(with display)
Wall Mounting Plate
Outdoor Unit
Power Cable
Fresh Air Filter
(on front of main filter in Specified Units)
Air inlet (rear)
Air inlet (side)
Air outlet
Air outlet (bottom)
Indoor Unit
(Interior / Air Handler)
Outdoor Unit
(Exterior / Condenser)
Refrigerant Pipe Connection
and Stop Valve (under cover)
Signal Cable
Connection from
Indoor Unit
Air inlet (rear)
Vertical Airflow Louver
Horizontal Airflow Grill (inside)
Smart Controller
Module USB Port
fig. 1.1
1
Overview
NOTE ON ILLUSTRATIONS
Illustrations in this manual are for explanatory purposes. The actual shape of your unit may vary.

MrCool Advantage Series Specifications

General

Refrigerant	R410A
Operating Temperature Range (Cooling)	5°F to 122°F
Dimensions (Indoor Unit)	Varies by model
Dimensions (Outdoor Unit)	Varies by model
Weight (Indoor Unit)	Varies by model
Weight (Outdoor Unit)	Varies by model
Type	Mini-Split Air Conditioner
Cooling Capacity	9, 000 - 36, 000 BTU
SEER Rating	Up to 22 SEER
Power Supply	208/230V, 60Hz
HSPF Rating	Up to 10 HSPF
