Page 8
Overview - Display
mrcool.com
1. Digital Display:
Displays the Temperature Setting when the air conditioner is operational.
Displays the Room Temperature when in FAN mode.
Displays Self-Diagnostic Codes:
Displays “ON” for three seconds when the Timer is ON and/or Fresh, Swing, Turbo or Silence
feature is activated.
Displays “OF” for three seconds when the Timer is switched OFF.
Displays “OF” for three seconds when the Fresh, Swing, Turbo or Silence feature is canceled.
Displays “dF” when Defrosting operation is active.
Displays “cF” when Anti-Cold Air feature is active in HEAT mode (when air temp is low).
Displays “SC” during Self Clean operation (if feature is available).
Displays “FP” when Freeze Protection is active, operating under 46.4 °F (8 °C) (if feature is
available).
2. Turbo Mode LED indicator:
Lights up when the Turbo Function is activated. The Turbo Function will maximize fan speed to
accelerate cooling to the desired temperature.
3. Defrost Mode LED indicator:
Lights up when the air conditioner begins defrosting automatically or when the warm air control
feature is activated in heating mode.
4. Run Mode LED indicator:
Lights up when the unit is in operation.
5. Timer Mode LED indicator:
Lights up during Timer Function .
NOTE: A guide for using the infrared remote - “Remote Manual” - is included in this literature package.
1
3
4
5
2
fig. 1.2
Display (on front panel of indoor unit) see fig. 1.2
turbo defrost run timer
