Unit Installation
Model Level Heat (SA2) Cool (SA1)
Fan Speed/Dip Switch Settings for MDUI18048E/MDUI18060E (4-5 Ton)
mrcool.com
Page 19
48K Indoor Unit
Dip Switches
Level 1 1 0 0 0 0 0 0 0
Level 2 1 0 0 1 0 0 0 0
Level 3 1 0 1 0 0 0 0 0
Level 4-Default 1 0 1 1 0 0 0 0
Level 5 1 1 0 0 0 0 0 0
Level 6 1 1 0 1 0 0 0 0
Level 7 1 1 1 0 0 0 0 0
Level 8 1 1 1 1 0 0 0 0
60K Indoor Unit
Dip Switches
Level 1 0 0 0 0 0 0 0 0
Level 2 0 0 0 1 0 0 0 0
Level 3 0 0 1 0 0 0 0 0
Level 4-Default 0 0 1 1 0 0 0 0
Level 5 0 1 0 0 0 0 0 0
Level 6
0
1
0
1
0
0
0
0
Level 7 0 1 1 0 0 0 0 0
Level 8
0
1
1
1
0
0
0
0
NOTE: 0 means position dip switch to on, 1 means position dip switch to number.
