Appliance Overview
Main Parts
Electric Box
Assembly
Centrifugal Fan
Fan Motor
Secondary Drain Pan
Evaporator
Assembly
Primary Drain Pan
Model
Cooling capacity (ton)
Optional electric heater (kW)
MDUI18024E / MDUI18036E
3.0
5-10
Model
Motor @ 230V ～, 60Hz
HP
FLA
MDUI18024E / MDUI18036E 1/2
2.1
Unit: inch (mm)
Model
Filter size
MDUI18024E / MDUI18036E
MDUI18048E
4.0
15
19-5/16 in x 20-5/16 in x 5/8 in (490 mm x 516 mm x 15 mm)
MDUI18048E / MDUI18060E
20-11/16 in x 20-5/16 in x 5/8 in (525 mm x 516 mm x 15 mm)
Fig. 1.2
MDUI18060E 5.0
15
MDUI18048E / MDUI18060E
3/4
3.2
NOTE
1. Dry coil and filter should be installed based upon nominal tonnage.
2. Use 0.96 as approximate SCFM correction factor for wet coil (optional).
