Maintenance and Cleaning
ASV without warning device
14
GB
Piston Spring
(1) Disassemble the spring from the groove by gently turning and drawing at the
same time.
(2) Check condition of spring (e.g. straightness, completeness of spring), replace
if necessary.
Valve Insert
(1) Unscrew valve insert with suitable tool (e.g. valve cap with integrated tool).
(2) Check sealings of the valve insert for flawless condition, replace if necessary
valve insert.
O-Rings
(1) Check O-rings for flawless condition, replace if necessary.
Reverse Valve
(1) Unscrew locking screw.
(2) By carefully knocking the housing on a suitable underground (e.g. wooden ta-
ble plate), remove components.
(3) Check spring and valve O-ring for flawless condition, replace if necessary.
Attention!
Do not deform spring!
