ASV without warning device
GB
17
5 Technical Data
(see also Operating Manual for MSA SCBA)
5.1 Materials
Medium pressure of SCBA:
( also Operating Manual for MSA SCBA)
approx. 7bar
Operation pressure of the compressed air
feeding line (Medium pressure):
max.: 8.5 bar
min.: 6.0 bar
Switching point from compressed air feed-
ing line to SCBA:
Compressed air feeding line pressure
4.5 + 1.0 bar
Switching point from compressed breath-
ing apparatus to compressed air feeding
line:
Compressed air feeding line pressure
6.0 ± 0.5 bar
Dimensions (over all)
Length (mm): 139
Width (mm): 18
Height (mm): 112
Connections
SCBA Plug nipple short
Compressed air breathing line apparatus Plug nipple long
Lung governed demand valve Locking coupling
Tool equipped with locking screw G1/4”
Valve housing Brass, nickel chrome plated
Connections Stainless steel, Brass, nickel plated
Fittings Stainless steel, Brass, nickel plated
