DF-8500 C Point type combustible gas detector with measuring range of 0~100%LEL
3.1.2 DF-8500 C Installation Diagram
Nut M6
Washer 6
Mounting plate
Washer 6
Bolt M6×12
Clamp 2 〃
DF-8500
Pipe 2 〃
DF-8500 C Mounting on Vertical pipe
DF-8500
Nut M6
Washer 6
Mounting plate
Washer 6
Bolt M6×12
Clamp 2 〃
Pipe 2 〃
DF-8500 C Mounting on horizontal pipe
Figure 4 DF-8500 C Installation Diagram
37
