DF
-
8500
C
测量范围为
0~10
0%LEL
的点型可
燃气体探测器
3.1.2 DF-8500 C
安装示意图
Nut/
螺母
M6
Washer/
弹簧
垫圈
6
Mounting plate/
安装板
Washer/
弹簧垫圈
6
Bolt/
螺栓
M6×
12
Clamp/
卡箍
2
〃
DF
-
8500
Pipe/
管道
2
〃
DF
-8500 C
竖直管安装
DF
-
8500
Nut/
螺母
M6
Washer/
弹簧垫圈
6
Mounting plate/
安装板
Washer/
弹簧
垫圈
6
Bolt/
螺栓
M6×
12
Clamp/
卡箍
2
〃
Pipe/
管道
2
〃
DF
-8500 C
水平管安装
图
4 DF-8500 C
安装示意图
9
7
9
