Type
Characteristic
Units
Correction
GRP102
Heel angle
–
–
Pitch angle
–
+
Heave
–
+
Down velocity
–
–
Down acceleration
–
–
GRP103
Heel angle
–
–
Pitch angle
–
+
Heave
–
+
Down velocity
–
–
Down acceleration
–
–
Inclinometer
Heel angle
Pitch angle
Roll period
Amplitude PORT
Amplitude STBD
EL6
Major semi-axis ellipse of errors
m
Minor semi-axis ellipse of errors
m
The angle of rotation of the ellipse errors
dg
EL0
Ellipsoid
Longitudinal speed source
Location determination
NK mode
EL1
Track angle
dg
EL4
Vertical Speed
knots
EL4
West East Speed
knots
EL4
North South Speed
knots
Cross track error
dg
Notes
1 «+» – value correction is available.
2 «–» – value correction is not available.
