13
Electrical Connections
Power Requirements
The Truck-Mounted Charging System can
consume enough current to eventually fully drain
the vehicle's battery, if the vehicle stands for
longer than a 12-hour period without supplemental
battery charging.
Therefore, it is recommended that the charger be
installed using any master ON/OFF switch where
power comes directly from the battery,
supplemental charger or connected to AC power
via a shoreline when the vehicle is stored.
Electrical Specifications
INPUT VOLTAGE
12.5 to 26.0 VDC (Fused at source)
RANGE
INPUT CURRENT
Less than 2.0 Amps DC
NORMAL BATTERY
2.5 Hours
CHARGE TIME
.
Installation
1. Connect the positive lead (red) on the
prepared wire end of the power supply line to
a fused, in-line connection with a master
switch. Connect to the switched side of
ignition or power source.
2. Connect the negative lead (black) of power
supply line to a confirmed ground.
3. With power source ON, confirm that the
power LED light is GREEN. If any other result
occurs, see "Troubleshooting Guidelines" in
the "Maintenance, Troubleshooting and
Service" section of this manual.
