G1 Facepiece
25
Ordering Information
GB
1 Nosecup 14 Lightpipe assembly, left
2A Harness, kevlar 15 Lightpipe assembly, right
2B Harness, rubber 16 Screw 30x8
3 Buckle D-ring 17 Inlet valve
4 Buckle 18 Inlet valve seat
5 Neck strap, cloth 19 Button, head harness
6 Neck strap, rubber 20 Speech diaphragm
7A Component housing Fixed Push-To-Connect 21 O-ring
7B Component housing Push-To-Connect 22 Inlet valve assembly
7C Component housing M45x3 23 Screw ring
8 Lens 24 Retainer, exhalation valve
9 Lens ring, upper 25 Exhalation valve assembly
10 Lens ring, lower 26 Retainer, inhalation valve
11A Cover, component housing
Fixed Push-To-Connect
27 Inhalation valve
11B Cover, component housing Push-To-Connect 28 Spring, exhalation valve
11C Cover, component housing M45x3 29 Pullstrap, head harness
12 Clamp, component housing 30 Adapter ESA
13 Screw, lens ring 31a/b Gasket
32 Sealing ring
