SENSOR TYPE
CALIBRATION RANGE
MSA PART NUMBER
WARNING LEVEL **
ALARM LEVEL **
Analysis Time (sec) ++
Extended
Analysis
Time (sec)
Extended Analysis Time Trigger
@ 1.5 SCFH
Flow Rate
@ 0.5 SCFH
Flow Rate
Sensor Increasing
Sensor
Decreasing
Rate Trigger
(per sec)
NITROGEN DIOXIDE
0-10 PPM
2.0 PPM **
4.0 PPM **
A
NA
100
0
2.0 PPM
(warning level)
-10
0.5 PPM
(0.50 X
warning level)
B
NA
20
80
1.8 PPM
(0.9 X warning level)
-10
C
NA
15
85
1.0 PPM
(0.5 X warning level)
-10
MODEL 3800
CARBON MONOXIDE
0-1000 PPM
100 PPM **
200 PPM **
A
90
NA
0
100 PPM
(warning level)
-1000
10 PPM
(0.10 X
warning level)
B
70
NA
20
90 PPM
(0.9 X warning level)
-1000
C
40
NA
50
50 PPM
(0.5 X warning level)
-1000
CHILLGARD RT +
REFRIGERANTS
0-1000 PPM
25 PPM **
50 PPM **
A
90
NA
0
25 PPM
(warning level)
-1000
10 PPM
(0.10 X
warning level)
B
70
NA
20
22.5 PPM
(0.9 X warning level)
-1000
C
40
NA
50
12.5 PPM
(0.5 X warning level)
-1000
