MSA MultiGard 5000 User Manual

MultiGard Custom System Definition
System Serial Number:
H17-400913267-11-001 & H17-400913267-11-002
End User:
Thermal Equipment Corp
Job Number:
400913267
ATO:
A-MG5000-C-B-A-B-0-0-A-A-A-B-C
Model:
Single 32
Processor Version:
3102-20 Rev 0
Display Version:
3102-21 Rev 0
System A
System B
Calibration Gases
Zero
Instrument Air
Comb
Propane .6% Span Value 20
CO
CO 60 PPM
Nominal Sensor Flow Rate
3 SCFH +/- .5 SCFH
Minimum Sensor Flow Rate
2 SCFH +/- .5 SCFH
Minimum Sample Line Flow Rate
8 SCFH +/- .5 SCFH
UCO Option # 1
X
Not Installed
(User Configured Outputs)
Form C Relays
Solid State Outputs
UCO Option # 2
X
Not Installed
(User Configured Outputs)
Form C Relays
Solid State Outputs
System Drawings
Drawing Number
DSK3103-
1045
Notes:
System is configured for BACNet
WAN side admin IP is 192.168.1.110:8080
LAN 10.10.79.103 BACNet, Processor 10.10.79.102, Display 10.10.79.101, Router 10.10.79.1
Panelview Plus 7, V9.0

MSA MultiGard 5000 Specifications

General

Brand	MSA
Model	MultiGard 5000
Category	Gas Detectors
Language	English
