MSA MultiGard 5000 User Manual

MultiGard Default User Parameters
Password
1
(Open System)
Sensor 1
Sensor 2
Sensor 3
Sensor 4
Trouble Set Points
-5
-5
(all points)
Warning Set Points
20
20
(all points)
Alarm Set Points
30
30
(all points)
Extended Analysis
100
100
(time rate trigger, inc. & dec.)
Extended Analysis
100
100
(increasing level trigger)
Extended Analysis
-100
-100
(decreasing level trigger)
Hysteresis
2
2
(in sensor EGU units)
Analysis Time (sec.)
90
Extended Analysis Time (sec.)
30
(based on slowest sensor)
Analysis Time System B
NA
Extended Analysis Time Sys. B
NA
(based on slowest sensor)
Trouble Relay
Warning Relay
Alarm Relay
Horn Relay
Latched/Non-latched
Latched
Non-Latched
Non-Latched
NA
Fail Safe/Non-Fail Safe
Fail-Safe
Non-Fail Safe
Non-Fail Safe
NA
On Delay (sec.)
0
0
0
0
Off Delay (sec.)
0
0
0
0
System B Latched/Non-latched
NA
NA
NA
NA
System B Fail Safe/Non-Fail Safe
NA
NA
NA
NA
System B On Delay (sec.)
NA
NA
NA
NA
System B Off Delay (sec.)
NA
NA
NA
NA
Days
Hours
Minutes
Timed Auto Standardize # 1
NA
NA
NA
Timed Auto Standardize # 2
NA
NA
NA
Timed Auto Standardize # 3
NA
NA
NA
