Third column; "Latched" through "Trouble Off Delay" - This column refers to the common trouble
relay parameters. By default trouble operates "Latched" and the push button will switch it to "NON-
Latched" operation. The "Trouble On Delay" is an on-delay numerical entry element that defaults to
zero seconds and has a valid entry range of 0-180 seconds. The "Trouble Off Delay" is an off-delay
numerical entry element that defaults to zero seconds and has a valid entry range of 0-180 seconds.
The trouble relay is always Failsafe (normally energized) and cannot be changed.
"Horn On Delay" - This horn on-delay numerical entry element defaults to zero seconds and has a
valid entry range of 0-180 seconds.
"Sensor 1 Hysteresis" through "Sensor 4 Hysteresis" - These four numerical entry elements allow
entry of a hysteresis value in engineering units for each sensor. These values apply to trouble,
warning and alarm level detection across all points associated with each sensor.
"System Menu" - An HMI navigation button which switches the screen to the System Setup Menu.
