8.1 MultiGard 5000 System Factory Configured Parameters
The factory parameters are derived from order entry information, the sensor complement in use, and
the results of applications engineering. This ensures proper system operation and integrity upon
delivery. All factory configured parameters are summarized below:
 Mode of Operation (8, 16, & Dual 8 Point or 24, 32, & Dual 16 Point)
 Analyzer(s) Ready Enable
 Sensor Low Engineering Units (per input)
 Sensor High Engineering Units (per input)
 Sensor Scaling for Voltage (V) or Current (I) (per input)
 Sensor Input Minimum V or I (per input)
 Sensor Input Maximum V or I (per input)
 Sensor Alarming Direction - Warning (per input)
 Sensor Alarming Direction - Alarm (per input)
 Sensor Type (per input)
 Sensor Engineering Units (per input)
 Auto Standardization (ASTD) Enable & Span Valve Selection (per input)
 Low ASTD Tolerances (per input)
 High ASTD Tolerances (per input)
 ASTD Duration: Zero, Span1, Span2, & Purge
 Enable Synthetic Span Gas Usage (per input)
 Synthetic Span Gas Conversion Parameters (per input): slope (m) and intercept (b)
 User Configured Output (UCO) Option #1 Enable
 UCO Option #2 Enable
 Version # for Logix Program
 S/N, B-Job #, MTO Code, & End User's Name
 Purge Operation? (per sensor)
 Purge Valve Selection
 Purge Set point (per sensor)
 Purge Duration
 Attached device combustible? (per sensor)
 Combustible W&A Set point Limit (per sensor) per FMRC Regulations
