Pressure level in
compressed air cylinder
LED display Visual representation
> 100 bar 2 green LEDs
< 100 bar and > 60 bar 2 yellow LEDs
< 60 bar (warning
signal/pressure alarm)
2 red LEDs
2 buddy lights
Reading out the Device using the MultiTAG-USB (125kHz/13,56MHz/NFC)
It is possible to read out the data from the SingleLineSCOUT. Settings can be changed to a certain extent
and reloaded back to the device. This is done by loading the MSA A2 Software on the PC.
See connected software manual in application software “SingleLine SCOUT”.
