MSA ULTIMA X5000 Safety Manual

Specifications
ULTIMA X5000 Gas Monitor Safety Manual 15
US
6. Specifications
Table 2 and Table 3 list specifications for the ULTIMA X5000 Gas Monitor. For a complete list of
specifications refer to the product instruction manual.
Table 2 Environmental/Electrical Specifications
Toxics & Oxygen Combustible Catalytic XIR PLUS
Operating temperature
range
-40°C to +60°C -40°C to +60°C -40°C to +60°C
Storage temperature
range
-40°C to +60°C -40°C to +60°C -40°C to +60°C
Humidity range 10-95% RH 0-95% RH 15-95% RH
Input voltage min 11 VDC
Input voltage nominal 24 VDC
Input voltage max 30 VDC
Table 3 Analog Output Default Values
Output Setting (mA) Custom 1 Custom 2 3.5 mA with HART 1.25 mA with HART
Fault 2.0 2.0 3.5 1.25
Calibration (excl. O
2
) 3.0 3.0 3.5 1.25
Calibration – O
2
only 3.0 21.7
3
3.5 1.25
Ready 4.0 4.0 4.0 4.0
WARN
1
Signal 5.6 5.6 5.6 5.6
ALARM
2
Signal 8.8 8.8 8.8 8.8
Over Range 21.7 21.7 21.7 21.7
1
Assumes alarm level of 10% full scale
2
Assumes alarm level of 30% full scale
3
For an O
2
sensor, 21.7 mA is the default Custom 2 setting and is not configurable.

MSA ULTIMA X5000 Specifications

General

Ingress Protection	IP66/67
Sensors	Electrochemical, infrared
Communication	HART, Modbus
Target Gases	Combustible gases, toxic gases, oxygen
Approvals	ATEX, IECEx, UL, CSA, SIL 2
