MSD 6014 User Manual

INSTALLATION INSTRUCTIONS 3
MSD • WWW.MSDPERFORMANCE.COM • (915) 855-7123 • FAX (915) 857-3344
PIN FUNCTION COLOR
A ECT BLACK
B Sensor Ground BROWN
C Coil 2 RED/GREEN
D Coil 4 BROWN/GREEN
E Coil 6 WHITE/BLUE
F Coil 8 VIOLET/BLUE
G 12V Supply PINK
H Battery + RED
J Ground BLACK
K 12V Supply PINK
L Coil 7 RED
M Coil 5 GREEN
N Coil 3 BLUE
P Coil 1 VIOLET
R Sensor Ground BROWN
S ECT YELLOW
PIN FUNCTION COLOR
A 12V PINK
B Ground BROWN
C Cam BROWN/WHITE
D Crank ORANGE/YELLOW
E 5V ORANGE
F Factory Use BLACK
G Not Used
H Step Retard PINK
J Launch Rev Limiter* BLUE
K Tach GRAY
16-Pin
Connector
10-Pin
Connector
2-pin connector connects to Engine Coolant Temp
(ECT) sensor.
Connect to Passenger's side coil connector.
(Coils 2-4-6-8)
Connect to a ground source.
Connect to Driver's side coil connector.
(Coils 1-3-5-7)
Connect to Relay or dedicated fused 30A switch.
2-pin connector connects to ECT sensor
Connect to Cam/Crank pigtail.
Step Retard is activated when 12V is supplied.
Tach output
When 12V is supplied, the Launch Rev Limiter RPM
value is active. (*Two Step)

MSD 6014 Specifications

General

Product Name	MSD 6014
Category	Controller
Type	Ignition Control
Rev Limiter	Yes
Voltage	12 V
Input Voltage	12 V
