Test bench MS008
4
INTRODUCTION
We appreciate you have chosen the products of TM MSG equipment.
The present user manual consists of the information on the application, supply slip, design,
specifications and rules of usage of test bench MS008.
Prior to using the test bench MS008 (hereinafter, “the bench”), study the present user manual
thoroughly. If required, get the special training at bench manufacturer facilities.
Due to the permanent improvements of the bench, the design, supply slip and software are
subject to modifications that are not included to the present user manual. Pre-installed bench
software is subject to update. In future, its support may be terminated without a prior notice.
1. APPLICATION
The bench is designed to perform the following tasks:
1. Evaluation of the technical condition of automotive alternators with alternating current rated
voltage 12 and 24V under the load up to 150 and 75A accordingly, including alternators of system
«start-stop» 12V.
2. Test of performance capacity of 12/24V voltage regulators - separately from alternators.
3. Diagnostics of automotive starters with power of 11kW, without load (at idle).
The diagnostics of automotive alternators and voltage regulators takes into account the following
criteria:
- Stabilizing voltage;
- control lamp working performance capacity;
- FR (displaying of the frequency and FR duty ratio, voltage regulator response).
- The AC pulsation value.
For COM alternator types (voltage regulators):
- ID;
- Protocol;
- data exchange speed;
- LIN protocol type;
- regulator self-diagnostics errors.
The diagnostics of the automotive starters considers the voltage changes nature and the currents
on the terminals 30, 45 and 50.
