The tester is a compact device supplied with a touch screen. A connector for diagnostic cable
connection is located in the upper part of the tester (Fig. 2), a MicroSD connector for software
updates - in its lower part (Fig. 3).
Two diagnostic cables are also included in the equipment set (Fig. 4, 5): a diagnostic cable and an
auxiliary cable to connect an additional positive contact.
Fig. 2. Connector for diagnostic cable.
Fig. 4. Four-wire diagnostic cable.
Fig. 3. MicroSD connector.
