Chapter 3 - System Assembly
3-5
Locate the DIMM slots and press down the
plastic clips towards both sides.
2. Installing Memory Modules
Insert the DIMM vertically into the slot
until the golden finger on the memory
module is deeply inserted in the socket.
Note: The DIMM has only one notch
on the center of module. It will only
fit in the right direction.
To Next Page
