MSI 870A Fuzion Power Edition series

2-12
Hardware Setup
MS-7660
Chapter 2
Hardware Setup
MS-7660
Chapter 2
IEEE 1394 Port
The IEEE 1394 port on the back panel provdes connecton to IEEE 1394 devces.
USB 3.0 Port
USB 3.0 port s backward-compatble wth USB 2.0 devces. Supports data transfer rate
up to 5 Gbt/s (SuperSpeed).
Important
If you want to use a USB 3.0 devce, you must use the USB 3.0 cable to connect to
the USB 3.0 port.
LAN
The standard RJ-45 LAN jack s for connecton to the
Local Area Network (LAN). You can connect a net-
work cable to t.
LED Color LED State Condton
Left Yellow O󰘯 LAN lnk s not establshed.
On(Steady state) LAN lnk s establshed.
On(brghter & pulsng) The computer s communcatng wth another computer on the LAN.
Rght
Green O󰘯 10 Mbts/sec data rate s selected.
On 100 Mbts/sec data rate s selected.
Orange On 1000 Mbts/sec data rate s selected.
Audo Ports
These audo connectors are used for audo devces. It s easy to d󰘯erentate between
audo e󰘯ects accordng to the color of audo jacks.
Lne-In (Blue) - Lne In, s used for external CD player, tape-player or other
audo devces.
Lne-Out (Green) - Lne Out, s a connector for speakers or headphones.
Mc (Pnk) - Mc, s a connector for mcrophones.
RS-Out (Black) - Rear-Surround Out n 4/ 5.1/ 7.1 channel mode.
CS-Out (Orange) - Center/ Subwoofer Out n 5.1/ 7.1 channel mode.
SS-Out (Gray) - Sde-Surround Out 7.1 channel mode.
▶
▶
▶
▶
■
■
■
■
■
■
Yellow Green/ Orange
