Hardware Setup
MS-7660
Chapter 2
2-25
Hardware Setup
MS-7660
Chapter 2
CPU Phase LEDs
These LEDs ndcate the current CPU power phase mode. Follow the nstructons below
to read.
Lghts O󰘯
CPU s n 2 phase power mode.
CPU s n 4 phase power mode.
CPU s n 6 phase power mode.
CPU s n 8 phase power mode.
Power LED
Every tme you press the power button and t s functonal, the power LED wll blnk
once.
Reset LED
Every tme you press the reset button and t s functonal, the reset LED wll blnk once.
GreenPower LED
Lghts when you press the GreenPower button to swtch the system’s LEDs on.
HDD LED
Lghts when the hard drve s operatng.
