MSI 915GM - Quick Components Guide

2-2
MS-7177 M-ATX Mainboard
Quick Components Guide
DDR DIMMs, p.2-7
Back Panel
I/O, p.2-10
CPU_FAN, p.2-15
ATX1, p.2-9
JFP1, p.2-18
PCI Slots 1~3,
p.2-22
F_USB1, F_USB2
, p.2-20
SATA1~SATA4,
p.2-17
CLR_CMOS1,
p.2-21
JC1, p.2-19
JPW1, p.2-9
PCI Express x16,
p.2-22
FDD1, p.2-15
IDE, p.2-16
SYS_FAN, p.2-15
F_AUD,p.2-20
CD_IN, p.2-16
AUX_IN, p.2-16
WOL, p.2-19
COM2, p.2-21
PWRFAN, p.2-15
JFP2, p.2-18
JLPC1, p.2-18
