MS-7695 Manboard
tRC
The row cycle tme determnes the mnmum number of clock cycles a memory row
takes to complete a full cycle, from row actvaton up to the prechargng of the actve
row.
tWR
Mnmum tme nterval between end of wrte data burst and the start of a precharge
command. Allows sense ampl󰘰ers to restore data to cells.
tRRD
Spec󰘰es the actve-to-actve delay of d󰘯erent banks.
tWTR
Mnmum tme nterval between the end of wrte data burst and the start of a column-
read command. It allows I/O gatng to overdrve sense ampl󰘰ers before read
command starts.
tRFC0/ 1
These settngs determne the tme RFC0/1 takes to read from and wrte to a memory
cell.
Advanced Channel 1/ 2 Tmng Con󰘰guraton
Press <Enter> to enter the sub-menu. And you can set the advanced memory tmng
for each channel.
tRWTT0/ tWRRD/ tWRWR/ tRDRD
These tems s used to set the memory tmngs for memory channel 1/ 2.
Bank Interleavng
Bank Interleavng s an mportant parameter for mprovng overclockng capablty of
memory. It allows system to access multple banks smultaneously.
NB Voltage/ DRAM Voltage/ SB Voltage
These tems are used to adjust the voltage of NB, memory and SB.
Overclockng Pro󰘰les
Press <Enter> to enter the sub-menu.
Overclockng Pro󰘰le 1/ 2/ 3/ 4/ 5/ 6
Press <Enter> to enter the sub-menu. In the sub-menu, these tems are used to save
the current settngs, and you can to load the settngs from the stored pro󰘰le.
CPU Spec󰘰catons
Press <Enter> to enter the sub-menu. The submenu shows the nformaton of nstalled
CPU.
CPU Technology Support
Press <Enter> to enter the sub-menu. The sub-menu shows the nstalled CPU
technologes. Read only.
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
