MSI B365M WIND User Manual

11
󶳧󱝾󴘭󸵅 󶳧󱝾󴘭󸵅
ATX_PWR1, CPU_PWR1: 󵫰󴻣󳰛󱿂
󸴐󱛩󳰚󱿂󱭩󸚞󳜁󸴗󳰚󱘈󱙂 ATX 󵫰󴻣󱡹󳍟󲏝
24
131
12
ATX_PWR1
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 Ground 15 Ground
4 +5V 16 PS-ON#
5 Ground 17 Ground
6 +5V 18 Ground
7 Ground 19 Ground
8 PWR OK 20 Res
9 5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 Ground
5
4
1
8
CPU_PWR1
1 Ground 5 +12V
2 Ground 6 +12V
3 Ground 7 +12V
4 Ground 8 +12V
󴱅󳞲
󶁢󸚊󳧟󴈄󳰚󱿂󸾋󳉛󴦜󶁢󵵙󸴗󳰚󱳭 ATX 󵫰󴻣󱡹󳍟󲏝󱘔󽘜󱝥󶁢󱣣󱙛󴋄󶍹󲷢󵵙󸳹󸀅
1
2
3
4
5
󴱅󳞲
y Intel
®
RST 󱜲󳻦󳬐󱯉󴈄 UEFI ROM 󵵙 PCIe M.2 󲓠󳗷󶁞󵷚
y 󷔫󵙗󲻘
®
󱩤󷇸 (Optane)™ 󱯜󲵙󳰛󱿂
30
M2_1: M.2 󳰛󱿂 (M 󹜗) (B365M PRO-VD, B365M PRO-VH,
B365M PLUS)
󲺽󲶾󸃔 M.2 󲓠󳗷󶁞󵷚 (SSD) 󳱥󱮦󷋼 M.2 󳰚󱿂󽘜󸛝󲤖󱘕󲓤󶆺

MSI B365M WIND Specifications

General

Form Factor	Micro ATX
Chipset	Intel B365
Socket	LGA 1151
Maximum Memory	64 GB
Memory Speed	DDR4 2666/2400/2133 MHz
Audio	Realtek ALC887
LAN	Realtek 8111H Gigabit LAN
RAID Support	RAID 0, 1, 5, 10
Storage Interface	6 x SATA 6Gb/s
USB Ports	6 x USB 3.1 Gen1, 6 x USB 2.0
Memory Slots	4 x DIMM
