18
Specifications
Continued from previous page
Internal Connectors
y 1x 24-pin ATX main power connector
y 1x 8-pin ATX 12V power connector
y 6x SATA 6Gb/s connectors
y 2x USB 2.0 connectors (support additional 4 USB 2.0 ports)
y 1x USB 3.1 Gen1 connectors (support additional 2 USB 3.1
Gen1 ports)
y 1x 4-pin CPU fan connector
y 1x 4-pin water-pump-fan connector
y 4x 4-pin system fan connectors
y 1x TPM module connector
y 1x Front panel audio connector
y 2x System panel connectors
y 1x Serial port connector
y 1x Parallel port connector
y 1x Chassis Intrusion connector
y 1x Clear CMOS jumper
y 1x 5050 RGB LED strip 12V connector
I/O Controller NUVOTON NCT6797 Controller Chip
Hardware Monitor
y CPU/System temperature detection
y CPU/System fan speed detection
y CPU/System fan speed control
Form Factor
y ATX Form Factor
y 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
BIOS Features
y 1x 128 Mb flash
y UEFI AMI BIOS
y ACPI 6.1, SM BIOS 2.8
y Multi-language
Continued on next page
