Overview of Components
Component Contents
Port Name Port Type Page
CPU_FAN1, PUMP_FAN1, SYS_FAN1~4 Fan Connectors 34
CPU_PWR1, ATX_PWR1 Power Connectors 32
DIMMA1, DIMMA2, DIMMB1, DIMMB2 DIMM Slots 28
JAUD1 Front Audio Connector 32
JBAT1 Clear CMOS Jumper 36
JCI1 Chassis Intrusion Connector 35
JCOM1 Serial Port Connector 34
JFP1, JFP2 Front Panel Connectors 31
JLPT1 Parallel Port Connector 36
JRGB1 RGB LED connectors 37
JTPM1 TPM Module Connector 35
JUSB1~2 USB 2.0 Connectors 33
JUSB3 USB 3.1 Gen1 Connector 33
M2_1 M.2 Slot (Key M) 30
PCI_E1~6 PCIe Expansion Slots 29
Processor Socket AM4 socket 27
SATA1~6 SATA 6Gb/s Connectors 31

MSI B450 TOMAHAWK MAX Specifications

General

Form Factor	atx
Chipset	amd b450
Processor Socket	socket am4
Processor Compatibility	amd ryzen 3 2000 series, amd ryzen 5 2000 series, amd ryzen 7 2000 series, amd ryzen 3 3000 series, amd ryzen 5 3000 series, amd ryzen 7 3000 series, amd ryzen 3 4000 series, amd ryzen 5 4000 series, amd ryzen 7 4000 series, amd ryzen 7
Maximum Memory	64 gigabytes
Power Connector	24-pin main power connector, 8-pin atx12v connector
PCI Bus Slots	5
Memory Slots	4

Weight and Dimensions

Width	12 inches
