MSI B75A-G43 GAMING series

En-9
Englsh
CPU & Cooler Installaton
When nstallng a CPU, always remember to nstall a CPU cooler. A CPU cooler s
necessary to prevent overheatng and mantan system stablty. Follow the steps below
to ensure correct CPU and CPU cooler nstallaton. Wrong nstallaton can damage both
the CPU and the motherboard.
Unhook and lft the loadng lever to
the fully open poston.
1.
The loadng plate should automatcally
lft up as the loadng lever s pushed
to the fully open poston.
Do not
touch any of the CPU socket pns.
2.
Lne up the CPU to 󰘰t the CPU
socket. Be sure to hold the CPU by
the base wth the metal contacts
facng downward. The algnment
keys on the CPU wll lne up wth the
edges of the CPU socket to ensure a
correct 󰘰t.
3. Close the loadng plate and remove
the plastc protectve cap.
4.
Algnment Key
