Specifications
Continued from previous page
WiFi & Bluetooth
Intel® Wi-Fi 6 AX200
∙ The Wireless module is pre-install in the M2_4 (Key-E)
slot
∙ Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-
5GHz (160MHz) up to 2.4Gbps
∙ Supports Bluetooth® 5
USB
∙ AMD® TRX40 Chipset
▪ 2x USB 3.2 Gen2 (SuperSpeed USB 10Gbps) ports (1
Type-A port on the back panel and 1 Type-C port through
the internal USB connector)
▪ 8x USB 3.2 Gen1 (SuperSpeed USB) ports (4 Type-A
ports on the back panel, 4 ports available through the
internal USB 3.2 Gen1 connectors)
▪ 4x USB 2.0 (High-speed USB) ports available through
the internal USB 2.0 connectors
∙ 3rd Gen AMD Ryzen™ Threadripper™ Desktop Processor
▪ 4x USB 3.2 Gen2 (SuperSpeed USB 10Gbps) Type-A
ports on the back panel
∙ ASMedia® ASM3242 Chipset
▪ 1x USB 3.2 Gen2x2 (SuperSpeed USB 20Gbps) Type-C
port on the back panel
Audio
∙ 1x Realtek® ALC1220 Codec
▪ 7.1-Channel High Definition Audio
∙ 1x Realtek® ALC4050H Codec
▪ Supports front & rear panel Mic-in
▪ Supports S/PDIF output
Back Panel
Connectors
∙ 1x Clear CMOS button
∙ 1x Flash BIOS Button
∙ 2x Wi-Fi Antenna connectors
∙ 5x USB 3.2 Gen2 Type-A ports
▪ 1x Flash BIOS Port
∙ 4x USB 3.2 Gen1 Type-A ports
∙ 1x USB 3.2 Gen2x2 Type-C port
∙ 2x LAN (RJ45) ports
∙ 5x OFC audio jacks
∙ 1x Optical S/PDIF OUT connector
Continued on next page
