Overview of Components
Component Contents
Port Name Port Type Page
CPU_FAN1, PUMP_FAN1,
SYS_FAN1~4, EXS_FAN1~3,
Fan Connectors 44
CPU_PWR1~2, ATX_PWR1 Power Connectors 36
CPU Socket Socket sTRX4 29
DIMM Slots Memory Slots 32
JAUD1 Front Audio Connector 43
JBAT1 Clear CMOS (Reset BIOS) Jumper 46
JBLK_D1, JBLK_U1 Base Clock Down & Up Header 45
JCI1 Chassis Intrusion Connector 47
JCORSAIR1 CORSAIR Connector 50
JFP1, JFP2 Front Panel Connectors 41
JOC_FS1 OC Force Enter BIOS Button 51
JOC_RT1 OC Retry Button 51
JPWRLED1 LED power input 52
JRAINBOW1~2 Addressable RGB LED connectors 49
JRGB1 RGB LED connector 48
JSLOW1 Slow Mode Booting Jumper 51
JTPM1 TPM Module Connector 46
JUSB1~2 USB 2.0 Connectors 42
JUSB3 USB 3.2 Gen2 Type-C Connector 42
JUSB4~5 USB 3.2 Gen1 Connectors 43
M2_1~3 M.2 Slots (Key M) 37
PCI_E1~4 PCIe Expansion Slots 34
POWER1, RESET1 Power Button, Reset Button 45
SATA1~6 SATA 6Gb/s Connectors 41
T_SEN1~3 Thermal Sensor Connectors 45
