CX600（MS-1682）Disassemble Guide
8、LOWER CASE ASSY
8.1：Remove the USB board cable as left pic
shows:
Component P/N Qty
USB board FPC K1C-1012039-J36 1
8.2：Remove the 1screw (M2.5*5mm)
Attention: the screw driver torque is 2.0-2.5Kgf-cm
Component P/N Qty
USB board 607-1682A-01S 1
Screw E43-1255007-H29 1
To Next Page
