CX600（MS-1682）Disassemble Guide
9、UPPER CASE ASSY
9.1：Remove the T/P module,
Component P/N Qty
Touchpad Module S78-3700360-SD2 1
Upper Case 307-682C111-TC7 1
9.2：Release the connector that stabilize the T/P
cable, then remove the T/P module FFC according
to direction of left pic shows;
Component P/N Qty
FFC Cable (To MB) K1C-1012040-J36 1
