CX61/CR61 (MS-16GB)Disassembly Guide
9、 LCD MODULE ASSY
9.1：When removing the LCD bezel, should begin
from the upside, then the two sides to downside.
Component P/N Qty
LCD Bezel 307-6G1B221-U22 1
9.2 ： Remove the 1 screw (M2.5*4mm), then
remove the left hinge cap.
Attention: the screw driver torque is 1.2-1.5Kgf-cm
Component P/N Qty
HINGE CAP_L E2P-6G10111-P89 1
screw E43-1254001-G68 1
