MSI CX61 - Remove Right Hinge Cap; Remove Left Hinge Screws; Remove Right Hinge Screws

CX61/CR61 (MS-16GB)Disassembly Guide
9、 LCD MODULE ASSY
9.3 ： Remove the 1 screw (M2.5*4mm), then
remove the right hinge cap.
Attention: the screw driver torque is 1.2-1.5Kgf-cm
Component P/N Qty
HINGE CAP_R E2P-6G10211-P89 1
screw E43-1254001-G68 1
9.4：Remove 3 screws (M2.5*4mm) that stabilize
the left hinge.
Attention: the screw driver torque is 3.0-3.5Kgf-cm
Component P/N Qty
screw E43-1254001-G68 2
Hinge L E2M-6G10112-G60 1
9.5：Remove 3 screws (M2.5*4mm) that stabilize
the right hinge.
Attention: the screw driver torque is 3.0-3.5Kgf-cm
Component P/N Qty
screw E43-1254001-G68 3
Hinge R E2M-6G10212-G60 1
