MSI CX70 - Remove Right Hinge Cap; Secure Left LCD Hinge; Secure Right LCD Hinge

CX70/CR70 (MS-1755) Disassembly Guide
9、 LCD MODULE ASSY
9.4： Remove the 1 screw (M2.5*4.5mm), then
remove the right hinge cap.
Attention: the screw driver torque is 1.5-2.0Kgf-cm
Component P/N Qty
HINGE CAP_R E2P-7510912-P89 1
screw E43-1254503-G68 1
9.5 ：Remove the 4 screws (M2.5*4.5mm) that
stabilize the left hinge.
Attention: the screw driver torque is 2.8-3.2Kgf-cm
Component P/N Qty
screw E43-1254503-G68 4
Hinge L E2M-7510412-G60 1
9.6 ：Remove the 4 screws (M2.5*4.5mm) that
stabilize the right hinge.
Attention: the screw driver torque is 2.8-3.2Kgf-cm
Component P/N Qty
screw E43-1254503-G68 4
Hinge R E2M-7510512-G60 1
